Understanding the intermittent bonded ribbon production line

Shanghai Weiye Optic Fiber Communication Equipment Co., Ltd. provides equipment for producing rollable formats used in optical-fiber manufacturing. Buyers can compare the capacity of this setup against their intended product range because it is designed for 12- and 16-fiber ribbons. Its split-type construction may also affect factory space and installation requirements.

Intermittent Bonded Ribbon Production Line
Compact Fiber Unit
Fiber Ribbone Line

The stated construction speed for this particular production line is 600 m/min. The process combines fiber pay-off, gathering and guiding, intermittent resin dispensing, UV-LED curing, visual monitoring, capstan pulling, and take-up. The complete process is important to evaluate, not just the stated speed.

Factory utilities, reel requirements, available floor space, and installation conditions should be reviewed before purchase. Ask the supplier for its documentation package and confirm the system’s suitability for your cable design and operating requirements. Addressing these details in advance may reduce setup delays and support a smoother start.

Key Takeaways

• Designed for rollable 12- and 16-fiber formats.
• Listed speed: 600 m/min for this equipment.
• Features a split-type construction.
• Curing, monitoring, pulling, and take-up stages are included.
• Check utilities, reels, installation needs, and supplier documents before buying.

Intermittent Bonded Ribbon Production Line

Explore The Intermittent Bonded Ribbon Production Line

To create rollable IBR formats, three mold groups position fibers for the application of small adhesive dots. Mold position is adjustable by operators from 0 to 15 mm, helping produce consistent spacing and form.

Produce Rollable Fiber Ribbons With Precision Bonding

The machine is supplied by a 16-spool pay-off, and guide rollers with U-shaped grooves help maintain the organization of each strand. Steady contact during processing is supported by the rollers’ hard-anodized surfaces. For 12F and 16F layouts, the adjustable valve setup uses 5+5+1 valves for 12 fibers or 5+5+5 for 16. Ask the supplier to verify tension control settings that suit your particular cable design.

Run 12- And 16-Fiber Configurations At Up To 600 m/min

Construction speed is listed at up to 600 m/min. Pay-off reel options hold 25.2 km or 50.4 km of fiber according to the listed reel dimensions: Φ236 mm × Φ25.4 mm × 108 mm and Φ267 mm × Φ25.4 mm × 180 mm. The system also offers T-type or fiber-optic take-up reels. Compare reel capacity with your operational requirements and expected changeover time.

Examine The Production Line’s Main Equipment And Controls

Tension, resin placement, and UV exposure must work together to maintain reliable output. Operators can use the system to match settings with the needs of their cable design and fiber ribbon.

Coordinate Fiber Tension, Resin Dispensing, And UV-LED Curing

Electro-pneumatic adjustment is used for each pay-off unit. Dispensers can run independently or in linked groups, with adhesive-dot spacing and counts configured through the interface.

Three pre-curing ovens serve the mold groups ahead of UV-LED post-curing. Ask the supplier to confirm resin compatibility and the relevant operating conditions.

The Siemens PLC and touchscreen display lamp current and oven temperature, generate alarms, and support preset lengths. Before purchase, verify cabinet requirements and power supply needs.

Plan Installation, Operating Conditions, And Line Configuration

Before the machine is delivered, set aside a dedicated operating area. An enclosed, clean, dry, draft-free space is needed for the optical fibre system. Keep the temperature from 15°C to 25°C, with humidity at or below 85%. These conditions help protect fiber equipment and maintain precision during operation.

With your facilities team, assess site utilities, available electrical capacity, cabinet space, and cable design. Nitrogen at 7 bar with 99.99% purity and compressed air at 6 bar are required for the system. A three-phase, five-wire electrical supply rated 380 V ±10% is specified.

• Allow space for the cabinet, components, resin, and access to service parts. Before starting the line, check the temperature settings and tension control.
• Account for the specified reel size of Φ410 mm × Φ50.8 mm × 391 mm. Reels of up to 30 kg can be handled by the take-up unit.
• Account for the main power feed-in cable when preparing the site. The equipment package does not include connection cables and cable trays.

The supply scope, reel types, and installation needs should be confirmed before placing an order. Reviewing these items may limit setup time and avoid subsequent delays. Ask the supplier to verify settings for your fiber and cable design, including lamp accuracy and operating conditions. A clear plan helps the production system begin operating more smoothly.

Obtain Pricing For A Ribbon Production Solution Matched To Your Needs

At its stated speed of 600 m/min, this line can be assessed by manufacturers producing rollable 12- or 16-fiber formats. Share details of your fiber layout, output targets, cable requirements, reel preferences, and factory conditions to obtain a quotation.

Check the proposed system for its 16-spool pay-off, UV-LED curing setup, take-up capacity, and included options. Before ordering, review the included components, dispensing-head options, unit functions, and cable design.

The documentation list includes operating and maintenance manuals, a general layout drawing, electrical schematics, and a wear-parts list. Reviewing these documents can help explain setup time and future service requirements.

For pricing and configuration details matched to your production plan and site utilities, consult Shanghai Weiye Optic Fiber Communication Equipment Co., Ltd. Verify the supply scope and replacement parts before purchase.
